Decon E-Drive
Decon E-Drive Power Add on System
Wheel Option Sizes 24"/22"/20"/16"
The E-Drive is a hub mounted, manual wheelchair joystick ( attendant controlled power assist for easier everyday flexibility. Choose from user or attendant joy-stick control and simply switch back to manual propulsion as and when desired.
For one E-Drive you need to order twice the same adapter (1xV / 1xH)
Check with us on what manual wheelchairs this will fit. ( Most major Manufacturers with fit)
If you are ordering this add on with joystick , it easier to fit with wheelchairs with height adjustable armrests.
When you receive your products, please check the packaging for damage. If so, contact us before signing to receive products.
What do you get ?
2 motor wheels in sizes 16 ", 20", 22 ", 24", 25 "or 26"
2 pieces of anodised aluminum / lacquered pushrims
Anti tippers ( Non Jackable)
Easy to program via joystick / computer/ app
Battery + battery charger
A battery case is included when choosing a battery under the seat or behind the back
Usermanual
2 year warranty
Decon E- Drive Technical Specifications
| Edrive Engine | 24V 120Wx2 |
| Battery type | Nickelmetallhybrid, 24Vx6,7 Ah (optional L i-ion, 25Vx11,8Ah) |
| Weight wheel (1pcs.) | 7 kg |
| Total weight | 16 kg (incl NiMH batteri) , 17,5 kg (incl Li-iON batteri) |
| Wheel dimensions | 16”, 20”, 22”, 24”, 25”, 26” |
| Air pressure | 6 Bar, 600 kPa |
| Speed | 0-6 km/h |
| Max range (with fully charged battery) | 24": ca NiMH 16 km, Li-ion ca. 30km. 16": 15 km NimH, 25 km Li-ion |
| Max userweight | Up to 125 kg |
| Max userweight “Heavy-duty” | Up to 150 kg |
| Max gradient | 6 degrees |
| Joystick | Contactless sensing of single-chip |
| Lever resistance change | Lever springs with different resistance levels |
| Display | LCD (Visible in sunlight) |
| Program parameters | Joystick or computer (Smart Tune) |
| Battery charger | 100 to 240V AC, 50/60Hz |
| Power rating | 37V. 26A (while charging) |
| Charging time | Normal charging ca. 2-3 hours |
